Product License Plate Recognition Camera ANPR Camera
  • LPR Camera
  • ANPR Camera
  • ALPR

Function Introduction

Wide Dynamic CMOS Image Sensor

Sony IMX327 star-level night vision effect, holographic restoration of color clarity and saturation, good low-light effect, more types of abnormal judgment, license plate contamination, bending, occlusion, shadow, rain and snow weather, etc. can identify

Optional Fixed Focus/Zoom Lens

Optional fixed focus 4, 6, 8, 12, 16, 25mm fixed focus lens and 8-18mm zoom lens, built-in 4 large LED white lights, identification and compensation Optical distance extended to 30 meters

Deep Learning Algorithm

Using deep learning algorithm to avoid misrecognizing other numbers on the car body, the recognition accuracy is higher, and the vehicle information can be quickly and accurately captured from various directions such as super-large angle license plates, oblique vehicles, and long-distance vehicles.

Recognition of All Types of License Plates

Supports more than 20 types of license plates, and can recognize more than 20 types of license plates such as blue license plates, yellow license plates, trailer license plates, police license plates, personalized license plates, Hong Kong and Macao entry and exit license plates, civil aviation license plates, and new energy license plates.

Vehicle Logo Recognition, Unlicensed Vehicle Detection

Support model recognition, vehicle logo recognition, vehicle color recognition, unlicensed vehicle detection rate / identification accuracy rate of large, medium and small vehicles > 96%

Output Dual Stream

Support simultaneous output of two streams of different resolutions, suitable for storage and viewing on different devices, support H.265 compression format, reduce bandwidth and storage space by 50%

Ready to Use

Fixed focus lens, no need to adjust, no need to set license plate width, ready to use

Cloud Platform Management

Supports remote viewing, control and debugging on PC side and small program side of Yiyunshikong camera management platform, which is convenient for management

Remote Debugging, Upgrade and Maintenance of Cameras

Relying on the Yiyunshikong camera management platform, remote debugging parameter configuration, upgrade and maintenance, and remote multi-station parking space group video monitoring management

Provide Standard Interfaces

Provide standard interfaces for users to expand applications, which can be applied to roadside parking management, parking lots, unattended weighing, automobile 4S stores and other industries

Product Superiority

High Accuracy of License Plate Recognition
Built-in Automatic Number Plate Recognition algorithm independently developed by Wintone technology based on deep learning, comprehensive Automatic Number Plate Recognition rate ≥ 99.9%
Fast Recognition Speed
Using video stream, video stream + ground sense two recognition modes, the video recognition speed reaches 25 frames/S, the picture recognition speed reaches 15 frames/S, and the delay time is within 100-200ms
Small Module Size and Easy Integration
Kuaihaotong Automatic Number Plate Recognition camera module is small in size, easy to integrate and apply
Strict Quality Control
Each equipment undergoes strict shock testing, high and low temperature testing, humidity testing, transportation testing and other hardware quality control processes and software testing
Gold Service
Provide on-site inspection, equipment installation and debugging guidance, regular inspection, life-long equipment maintenance and other services, all-day customer service on duty, and timely response to after-sales calls

Application Scenarios

  • Intelligent inspection vehicle
  • Unattended weighing
  • 4S shop car maintenance
  • Intelligent car washing
  • Smart gas station
  • Non-inductive payment
Intelligent inspection vehicle

The wintone technologyAutomatic Number Plate Recognition camera is installed on the front, rear and side of the back seat equipment of the inspection vehicle. The patrolman rides along the parking space, and the camera automatically captures the license plate information of the parked vehicle. Recognition of license plates in different parking positions such as vertical parking and large-angle inclination, and capture license plate information in an all-round way. One person and one electric vehicle can manage hundreds of parking spaces, greatly improving the efficiency of patrol inspection, and interacting with the road parking electronic toll collection system in real time. Realize the creation and settlement of parking orders, and intelligent parking charges.

Unattended weighing

The Wintone intelligent Automatic Number Plate Recognition camera uses the embedded license plate recognition modular structure and networked, TCP/IP protocol data transmission mode, without the need for an industrial computer to automatically detect vehicles, obtain vehicle information, and send the data to the system host through the network. Intelligent management of vehicle entry and exit and cargo transportation, the car can complete the entire weighing process quickly, accurately, safely, stably and reliably without human intervention, and realize the full intelligence of data collection in the measurement process.

4S shop car maintenance

Through the application of wintone technology Automatic Number Plate Recognition cameras, refined management and visual service management of vehicles entering and leaving the 4S store can be carried out, providing the management with the data basis for decision analysis, and improving the management level and service level of the 4S store.

Intelligent car washing

The Automatic Number Plate Recognition camera is connected to the intelligent car wash system. Before the vehicle arrives at the store, the vehicle information can be obtained in advance, which is convenient for the vehicle to enter the car wash machine quickly, reduces the waiting time of the vehicle in line, and improves the profit of the car wash room.

Smart gas station

The application of Automatic Number Plate Recognition camera can realize the intelligent payment experience such as senseless license plate payment and face payment through integrated application. After theAutomatic Number Plate Recognition results are obtained, the system can collect and analyze the big data of the vehicles that usually refuel , so as to carry out precision marketing and bring more loyal customers to the gas station; More and more gas stations have begun to use automatic car washing equipment to provide free car washing services for vehicles that have reached a certain amount of refueling, so as to quickly and accurately judge whether the vehicles are qualified for free automatic car washing, so as to control the automatic lifting of the equipment. The whole process is rapid and convenient without manual intervention.

Non-inductive payment

The combination of the Automatic Number Plate Recognitioncamera and the sensorless payment system can automatically and accurately verify the vehicle identity, shorten the waiting time for vehicle payment, improve the efficiency of vehicle traffic, and avoid congestion.

Case

License plate recognition camera applied to smart logistics park platform
LPR camera enables unattended weighbridge management and scientific weighing overload management

Product parameters

  • ALPR
    Sheet Metal Material/Thickness Memory CPU frequency Communication method Voice broadcast Protection configuration
    Galvanized sheet/ 1.5mm 2GB 4-core 1.6GHz 4G/WIFI/RJ45、RS485 "Yuyin Tianxia" voice chip Waterproof groove + hard foam + heaven and earth lock
    Detalis
    Dimensions 360x1460mm
    Weight Box packing 14kg, column packing 7.5kg
    Plastic powder Silver/
    Aksu Outdoor Powder
    Imaging parameters Sensor dynamic range 95db
    LED screen Four lines, three colors, 4 characters width, 450cd/m2 brightness adjustable
    Speech synthesis Support any Chinese and English playback, power 8W, volume adjustable
    Input 100-240VAC
    Total power 50W
    Operating temperature -35 to 85 degrees Celsius
    Protection class IP65
    Communication method RJ45、RS485
    Secondary development Support Windows platform C++\Java\C#\Delphi secondary development
    Sheet metal material/thickness Galvanized sheet/1.5mm
    Memory 1GB (standard version), 2GB (high version)
  • ANPR Camera
    CPU frequency Memory Built-in storage GPU Sensor version
    4 cores 1.5GHz 2G/1G 8/4GB Rockchip RV1126  Sony IMX327
    Detalis
    Model EP-B622 (4\6\8\12\16\25)
    Department; EP-B652 (4\6\8\12\16\25)
    Department; EP-B652 (B)
    Module MV6B-A(4\6\8\12\16\25),MV6B-B(4\6\8\12\16\25)
    MV6B-B(B)
    Motherboard Main chip: RV1126 4-core CPU, 1-core NPU, main frequency 1.5GHz
    DDR: 2 Samsung 512MB, total 1GB
    eMMC: 1 Samsung 4GB storage
    Sensor version Sony IMX327,
    200W 1/2.8 inch, WDR, starlight CMOS image sensor
    Interface board Power interface, SD card interface, network interface,
    Function interface (1 IO input, 1 relay output, 1 RS485)
    Expansion board 3-way IO input, 2-way relay output, 1-way RS485, 1-way MIC, 1-way passive speaker, 1-way active speaker
    Light board 4 imported CREE high-brightness white LED lamp beads, up to 30m
    Fixed focus lens 200W 4mm, 6mm, 8mm, 12mm, 16mm, 25mm fixed focus lens aperture F1.6 (except 25mm)
    Zoom lens 200W zoom 3-25m, aperture F1.6
  • LPR Camera
    Imaging device Power supply Shell material Protection class Recognition distance
    Wide dynamic CMOS image sensor POE powered Aluminum alloy IP66 2-8 meters
    Detalis
    Imaging device 1/2.7-inch, 2-megapixel low-light, wide dynamic CMOS image sensor
    Image adjustment Exposure gain automatic adjustment
    lens Fixed focus 6mm M12 interface (different focal length lenses are optional)
    Fill light White light LED always bright fill light, fill light distance 2m-8m
    Video compression format  H.264、MJPEG
    Video output 1080P(1920x1080), 720P(1280x720), D1(704x576), CIF(352x288) frame rate and resolution can be configured according to bandwidth
    Image output 2 million pixel JPEG
    Communication interface  10/100M network adaptive, RJ45 network interface, built-in 4G (full Netcom), WIFI2.4G (4G and WIFI optional)
    Audio interface Audio output, speech synthesis (male and female voices can be configured)
    Serial interface 1 channel RS485
    IO interface 2-way optocoupler isolation input, 2-way relay output, button to restore factory settings
    Power supply mode External power input (DC12V/2A)/POE power supply Comply with IEEE802.3AT PD standard (maximum 12W)
    Equipment power fixed 10W
    Protection class IP66
    Shell material aluminum alloy
